high performance light barriers - amplifiers

OV584910

OV584910
List price
152,20 €
Not in stock
high performance light barrier amplifier, 76x78x40mm, Change-over contact (NO/NC), Plug-in connection 11pin, IP40, Plastic

high-performance light barriers

230V AC,Relais,alarm,auto

Mechanical features

Mounting method
Pluggable
Height
76.5mm
Design
Cuboid
Housing material
Plastic
Width
40mm
Depth
78.5mm
Length
78.5mm
Degree of protection (IP)
IP40

Electrical features

Operating voltage
230V
Number of channels
1
Switching capacity
120VA
Type of voltage supply
Active
Switching frequency
11Hz
Type of switching function
Change-over contact (NO/NC)
Output circuit, relay change-over contact
1
Max. switching distance
50m
No-load current
21mA
Number of presets to be set
4
Switching voltage AC
230
Voltage type
AC
Power consumption
4.8W
Number of pins
11
Switching voltage
230V
Type of electrical connection
Plug-in connection
Rated switching current
5A
Input voltage tolerance
10%
Malfunction message output
no
yes
Switching voltage DC
24V
High performance light barriers
yes

Other features

Operating temperature
-25 - 50°C

High performance light barrier, transmitter

High performance light barriers, receiver

Accessories OV58

ClassificationClass
eClass 7.027210121
eClass 7.127210121
eClass 8.027210121
eClass 9.027210121
eClass 9.127210121
ETIM-6.0EC001485
ETIM-7.0EC001485
IPF Product Group101
PropertyValue
shipping weight0.25kg
packaging dimensions80mm x 45.0mm x 120mm
customs tariff number85365080
