High performance light barriers - Amplifier
OV634915
| amount | price | discount |
|---|---|---|
| 1 | 165,10 € | – |
| 5 | 160,15 € | 3% / 4,95 € |
| 10 | 156,85 € | 5% / 8,26 € |
| 20 | 151,89 € | 8% / 13,21 € |
| 50 | 145,29 € | 12% / 19,81 € |
On demand
High performance light barrier, amplifier, 58x95x53mm, 230V AC, Change-over contact (NO/NC), Clamp, IP20, Plastic, Malfunction message output
Compare
High performance light barriers - Amplifier
Electrical properties
- Number of presets to be set
- 2
- Number of channels
- 1
- Number of contacts as change-over contact
- 1
- Number of switching outputs
- 1
- Number of normally open contacts
- 1
- Type of switching function
- Change-over contact (NO/NC)
- Type of alarm output
- Relay contact
- Type of electrical connection
- Clamped terminal connection
- Type of switching output
- Relay contact
- Rated switching current
- 100mA
- Input voltage tolerance
- 10%
- Setting procedure
- Potentiometer
- No-load current
- 20mA
- Power consumption
- 4.8VA
- Switching distance
- 0 - 50,000mm
- Switching function of the alarm output
- Normally open contact (NO)
- Switching capacity
- 1,150VA
- Switching voltage
- 230V
- Switching voltage AC
- 230V
- Switching voltage DC
- 24V
- Operating voltage (AC 50Hz)
- 207 - 253V
- Display
- LED display
- Malfunction message output
- Yes
- With soiling compensation
- Yes
Mechanical properties
- Design
- Cuboid
- Width
- 52.8mm
- Height
- 58mm
- Length
- 90mm
- Mounting method
- Top hat rail
- Degree of protection (IP)
- IP20
- Housing material
- Plastic
Optical properties
- Range (transmitter with increased power, receiver with short design)
- 10
- Range (transmitter with increased power, receiver with normal design)
- 20
- Range (transmitter with maximum power, receiver with short design)
- 20
- Range (transmitter with maximum power, receiver with normal design)
- 50
- Range (transmitter with normal power, receiver with short design)
- 8
- Range (transmitter with normal power, receiver with normal design)
- 15
Other properties
- Ambient temperature
- -25 - 50°C
High performance light barriers, receiver
High performance light barrier, transmitter
Accessories OV54/62/63/64/65
Datasheets
Manuals
Drawings
Product Compliance
-
pdfUKCA declaration of conformityPDF-file, 325 KB
-
pdfMaterial compliancePDF-file, 407 KB
-
pdfCE declaration of conformityPDF-file, 253 KB
Miscellaneous
| Classification | Class |
|---|---|
| eClass-7.0 | 27210121 |
| eClass-7.1 | 27210121 |
| eClass-8.0 | 27210121 |
| eClass-9.0 | 27210121 |
| eClass-9.1 | 27210121 |
| ETIM-6.0 | EC001485 |
| ETIM-7.0 | EC001485 |
| Property | Value |
|---|---|
| RoHS‑compliant | Yes |
| Reach-compliant | Yes |
| IPF Product Group | 101 high performance through-beam sensors and amplifiers |
| packaging dimensions | 60 x 65 x 100mm |
| gross weight | 250g |
| Customs tariff number | 85365080 |
| WEEE number | 40951076 |
