Diffuse-reflections sensor for integration - mechanical

YM22C839

YM22C839
List price
82,20 €
amount price discount
1 82,20 € –
5 79,73 € 3% / 2,47 €
10 78,09 € 5% / 4,11 €
20 75,62 € 8% / 6,58 €
50 72,34 € 12% / 9,86 €
Available
sensor mechanical, push button, M22x1 20long, 22.5mm, 24V DC, -40-75°C, Relay contact NO, Cable 6pin 1500m, IP68, V4A, With LED display
including 1x Nut, 1x Sealing ring
circuit diagram
Compare

Diffuse-reflections sensor for integration - mechanical

Electrical properties

Type of switching function
Normally open contact (NO)
Type of electrical connection
Cable
Type of switching output
Relay contact
Rated switching current
200mA
Short-circuit protection
Yes
No-load current
20mA
Line diameter
4mm
Number of pins
6
Voltage drop
2.5V
Reverse polarity protection
Yes
Operating voltage (AC 50Hz)
24V
Operating voltage (DC)
24V
Display
LED display

Mechanical properties

Design
Round
Thread length
12mm
Thread pitch
1mm
Cable length
1.5m
Length
20mm
Hole diameter
22.5mm
Maximum tightening torque
1Nm
Mounting method
Counter thread
Degree of protection (IP)
IP68
Front ring material
Metal
Housing material
Stainless steel 1.4404
Thread dimension
M22

Other properties

Ambient temperature
-40 - 75°C
With front ring
Yes
Print data
Classification Class
eClass-7.0 27371228
eClass-7.1 27371228
eClass-8.0 27371228
eClass-9.0 27371228
eClass-9.1 27371228
ETIM-6.0 EC001028
ETIM-7.0 EC001028
Property Value
RoHS‑compliant Yes
Reach-compliant Yes
POP-compliant Yes
IPF Product Group 690 diverse sensors
packaging dimensions 124 x 28 x 149mm
gross weight 140g
Customs tariff number 85365019
WEEE number 40951076
