| amount | price | discount |
|---|---|---|
| 1 | 53,70 € | – |
| 5 | 52,09 € | 3% / 1,61 € |
| 10 | 51,02 € | 5% / 2,69 € |
| 20 | 49,40 € | 8% / 4,30 € |
| 50 | 47,26 € | 12% / 6,44 € |
The IB080121 inductive sensor is manufactured in accordance with EN 60947-5-2 and recognizes conductive metals at short distances. It is insensitive to other materials and is therefore particularly suitable for use in soiling or harsh environments. The switching distance of the sensor is set at the factory to 1.5mm, measured with a norm measuring plate corresponding to the sensor surface.
The sensor has a cylindrical housing made of stainless steel 1.4305 with an M8x1mm thread and an electrical connection with a 3-pin M12 connector. It can be flush-mounted and is suitable for standard applications.
| Classification | Class |
|---|---|
| eClass-7.0 | 27270101 |
| eClass-7.1 | 27270101 |
| eClass-8.0 | 27270101 |
| eClass-9.0 | 27270101 |
| eClass-9.1 | 27270101 |
| ETIM-6.0 | EC002714 |
| ETIM-7.0 | EC002714 |
| Property | Value |
|---|---|
| RoHS‑compliant | Yes |
| Reach-compliant | Yes |
| OzDS-compliant | Yes |
| POP-compliant | Yes |
| TSCA-compliant | Yes |
| IPF Product Group | 200 inductive sensors |
| packaging dimensions | 100 x 17 x 120mm |
| gross weight | 20g |
| 0,12kg CO₂e | |
| Customs tariff number | 85365019 |
| WEEE number | 40951076 |
