High performance light barriers - Amplifier
OV584901
| amount | price | discount |
|---|---|---|
| 1 | 178,70 € | – |
| 5 | 173,34 € | 3% / 5,36 € |
| 10 | 169,77 € | 5% / 8,94 € |
| 20 | 164,40 € | 8% / 14,30 € |
| 50 | 157,26 € | 12% / 21,44 € |
On demand
High performance light barrier, amplifier, 76x78x40mm, 115V AC, PNP/NPN Change-over contact (NO/NC), Plug-in connection 11pin, IP40, Plastic
Compare
High performance light barriers - Amplifier
Electrical properties
- Number of presets to be set
- 2
- Number of channels
- 1
- Number of contacts as change-over contact
- 1
- Number of switching outputs
- 1
- Type of switching function
- Change-over contact (NO/NC)
- Type of electrical connection
- Plug-in connection
- Type of switching output
- PNP/NPN
- Rated switching current
- 5,000mA
- Input voltage tolerance
- 10%
- Setting procedure
- Potentiometer
- No-load current
- 26mA
- Power consumption
- 5VA
- Number of pins
- 11
- Switching frequency
- 18Hz
- Switching voltage
- 115V
- Switching voltage AC
- 230V
- Switching voltage DC
- 24V
- Operating voltage (AC 50Hz)
- 103.5 - 126.5V
- Display
- LED display
Mechanical properties
- Design
- Cuboid
- Width
- 40mm
- Height
- 76.5mm
- Length
- 78.5mm
- Mounting method
- Relay base
- Degree of protection (IP)
- IP40
- Housing material
- Plastic
Other properties
- Ambient temperature
- -25 - 60°C
You can find accessories for OV584901
in these product groups:
Accessories OV58
High performance light barrier, transmitter
High performance light barriers, receiver
Datasheets
Manuals
Drawings
Product Compliance
-
pdfUKCA declaration of conformityPDF-file, 325 KB
-
pdfMaterial compliancePDF-file, 407 KB
-
pdfCE declaration of conformityPDF-file, 254 KB
Miscellaneous
| Classification | Class |
|---|---|
| eClass-7.0 | 27210121 |
| eClass-7.1 | 27210121 |
| eClass-8.0 | 27210121 |
| eClass-9.0 | 27210121 |
| eClass-9.1 | 27210121 |
| ETIM-6.0 | EC001485 |
| ETIM-7.0 | EC001485 |
| Property | Value |
|---|---|
| RoHS‑compliant | Yes |
| Reach-compliant | Yes |
| IPF Product Group | 101 high performance through-beam sensors and amplifiers |
| packaging dimensions | 80 x 45 x 120mm |
| gross weight | 250g |
| Customs tariff number | 85365080 |
| WEEE number | 40951076 |
