Laser sensors - Contrast sensor
PK170020
| amount | price | discount |
|---|---|---|
| 1 | 704,00 € | – |
| 5 | 682,88 € | 3% / 21,12 € |
| 10 | 668,80 € | 5% / 35,20 € |
| 20 | 647,68 € | 8% / 56,32 € |
| 50 | 619,52 € | 12% / 84,48 € |
On demand
sensor laser, contrast, 50x50x15mm, Sn: 0-250, 12-30V DC, 4-20mA, Connector M12 4pin, Zinc die-cast
Compare
Laser sensors - Contrast sensor
Contrast scanners are capable to distinguish the the visual differences (e.g. reflectivity, brightness differences) between adjacent areas. In general, the devices project a light spot on an object's surface and analyze the reflected light. Fiber optic amplifier versions can be used in addition to the incident light mode also in the transmitted light mode. Contrast scanners are versatile. They can be used, among other things, for position control of printing or color marks, distinction of brightness variations or in the intensity control of luminous objects (like LEDs, displays etc.).
Electrical properties
- Type of analog output
- 4 - 20mA
- Type of electrical connection
- Connector M12
- Rated switching current
- 200mA
- Number of pins
- 4
- Switching distance
- 0 - 250mm
- Voltage drop
- 2V
- Display
- LED display
- Short circuit protection, Reverse polarity protection
Mechanical properties
- Design
- Cuboid
- Width
- 15.4mm
- Height
- 50mm
- Length
- 50mm
- Housing material
- Zinc die-cast
Optical properties
- Laser class
- Class 1
- Light beam form
- Point
- Wavelength of the sensor
- 650nm
Other properties
- Ambient temperature
- -10 - 50°C
You can find accessories for PK170020
in these product groups:
Assembly
Fixing material design 17
Available
Mounting system for AY000119
Available
Connection technology
Cable sockets M12 4-wire
Cable sockets M12 4-wire shielded
Cable sockets M12-socket M12-connector 4-wire
Datasheets
Drawings
Product Compliance
-
pdfUKCA declaration of conformityPDF-file, 474 KB
-
pdfMaterial compliancePDF-file, 481 KB
-
pdfEU declaration of conformityPDF-file, 255 KB
-
pdfUL declaration of conformityPDF-file, 254 KB
-
pdfCCC declaration of conformityPDF-file, 248 KB
-
pdfCSA declaration of conformityPDF-file, 243 KB
Product flyers
Whitepapers
| Classification | Class |
|---|---|
| eClass-7.0 | 27270906 |
| eClass-7.1 | 27270906 |
| eClass-8.0 | 27270906 |
| eClass-9.0 | 27270906 |
| eClass-9.1 | 27270906 |
| ETIM-6.0 | EC001820 |
| ETIM-7.0 | EC001820 |
| Property | Value |
|---|---|
| RoHS‑compliant | Yes |
| Reach-compliant | Yes |
| OzDS-compliant | Yes |
| POP-compliant | Yes |
| TSCA-compliant | Yes |
| IPF Product Group | 168 laser contrast readers |
| packaging dimensions | 77 x 25 x 123mm |
| gross weight | 120g |
| 3,1kg CO₂e | |
| Customs tariff number | 85365019 |
| WEEE number | 40951076 |
