| amount | price | discount |
|---|---|---|
| 1 | 207,40 € | – |
| 5 | 201,18 € | 3% / 6,22 € |
| 10 | 197,03 € | 5% / 10,37 € |
| 20 | 190,81 € | 8% / 16,59 € |
| 50 | 182,51 € | 12% / 24,89 € |
Linking digital signals directly at the machine can help to minimize costs and effort considerably. A classic application is the linking of different signals directly in the field. This avoids long cable runs between many individual devices, significantly minimizes the wiring effort and reduces the need for control inputs. All input signals on the logic modules are visualized by integrated LEDs and are electrically decoupled from each other. This reliably prevents influences from one device to the other. The modules' outputs are overload-proof and the pending signal is also indicated via an LED. Along with logical input signal links such as AND or OR, versions with signal change control are also available. The ipf logic modules are available for top-hat rail mounting or as field modules. Because of this and the robust housing, which is characterized by a high degree of protection against the ingress of dust and water, our devices can be used in all areas of machines, systems and tools.
| Classification | Class |
|---|---|
| eClass-7.0 | 27242216 |
| eClass-7.1 | 27242216 |
| eClass-8.0 | 27242216 |
| eClass-9.0 | 27242216 |
| eClass-9.1 | 27242216 |
| ETIM-6.0 | EC001417 |
| ETIM-7.0 | EC001417 |
| Property | Value |
|---|---|
| RoHS‑compliant | Yes |
| Reach-compliant | Yes |
| TSCA-compliant | Yes |
| IPF Product Group | 800 miscellaneous |
| packaging dimensions | 99 x 60 x 160mm |
| gross weight | 270g |
| 1,34kg CO₂e | |
| Customs tariff number | 85365005 |
| WEEE number | 40951076 |
