Push button for integration - mechanical

YM220100

YM220100
List price
75,20 €
amount price discount
1 75,20 € –
5 72,94 € 3% / 2,26 €
10 71,44 € 5% / 3,76 €
20 69,18 € 8% / 6,02 €
50 66,18 € 12% / 9,02 €
Available
Sensor Mechanical, push buttons, M22x1 20long, 22.5mm, 24V DC, -40-75°C, relay contact NO, single core 6-pole 0.5m, IP68, V4A, LED
including Nut
circuit diagram
dimensional drawing
3D model
Compare

Push button for integration - mechanical

Electrical properties

Type of switching function
Normally open contact (NO)
Type of electrical connection
Single cores
Type of switching output
Relay contact
Rated switching current
200mA
No-load current
20mA
Number of pins
6
Voltage drop
2.5V
Display
Short circuit protection, Reverse polarity protection
Operating voltage
Electrical connection

Mechanical properties

Design
Round
Thread length
12mm
Thread pitch
1mm
Cable length
0.5m
Length
20mm
Hole diameter
22.5mm
Maximum tightening torque
1Nm
Mounting method
Counter thread
Degree of protection (IP)
IP68
Front ring material
Metal
Housing material
Stainless steel 1.4404
Thread dimension
M22
dimensions

Other properties

Ambient temperature
-40 - 75°C
Classification Class
eClass-7.0 27371228
eClass-7.1 27371228
eClass-8.0 27371228
eClass-9.0 27371228
eClass-9.1 27371228
ETIM-6.0 EC001028
ETIM-7.0 EC001028
Property Value
RoHS‑compliant Yes
Reach-compliant Yes
POP-compliant Yes
TSCA-compliant Yes
IPF Product Group 690 diverse sensors
packaging dimensions 43 x 43 x 105mm
gross weight 58g
0,85kg CO₂e
Customs tariff number 85365011
WEEE number 40951076
