Inductive sensors - Switching amplifier for high temperature sensors

IV400720

IV400720
List price
181,20 €
amount price discount
1 181,20 €
5 175,76 € 3% / 5,44 €
10 172,14 € 5% / 9,06 €
20 166,70 € 8% / 14,50 €
50 159,46 € 12% / 21,74 €
Available
amplifier inductive, High-temperature, 42x86x40mm, 10-30V DC, PNP Normally open/normally closed, Plug-in connection M12 4pin, IP65, Aluminum, With LED display
Compare

Inductive sensors - Switching amplifier for high temperature sensors

Inductive proximity switches are contact-free sensors. They detect all conductive metals, regardless of whether they move or not. The achievable sensing range of the devices depends on the object material and its dimensions. The vibration-resistant sensors can be approached laterally or frontally. Inductive proximity switches are used for presence detection (e.g. goods carriers), positioning (e.g. dampers), counting (e.g. nuts /bolts), speed detection (e.g. for cog wheels), on conveyor systems (e.g. hose feedings) or distance measurements (e.g. press-in checking) of metallic objects.

Electrical properties

Number of channels
1
Type of switching function
Normally open/normally closed
Type of electrical connection
Connector M12
Type of switching output
PNP
Rated switching current
200mA
Short-circuit protection
Yes
No-load current
25mA
Number of pins
4
Switching frequency
1,000Hz
Switching capacity
4.8VA
Switching voltage
24V
Voltage drop
2V
Reverse polarity protection
Yes
Operating voltage (DC)
10 - 30V
Display
LED display
Malfunction message output
Yes
Amplifier for inductive sensors
Yes

Mechanical properties

Design
Cuboid
Width
40mm
Height
42mm
Length
74.5mm
Mounting method
Floor fastening
Degree of protection (IP)
IP65
Housing material
Aluminum

Other properties

Ambient temperature
-25 - 75°C
Version
Field device
You can find accessories for IV400720 in these product groups:

Cable sockets M12 3-wire

Cable sockets M12 4-pin field attachable

Cable sockets M12 5-pin field attachable

Inductive high-temperature sensors connection with amplifier

Cable sockets M12 4-wire shielded

Cable sockets M12 4-wire

Classification Class
eClass-7.0 27210121
eClass-7.1 27210121
eClass-8.0 27210121
eClass-9.0 27210121
eClass-9.1 27210121
ETIM-6.0 EC001485
ETIM-7.0 EC001485
Property Value
RoHS‑compliant Yes
Reach-compliant Yes
IPF Product Group 202 inductive sensors (high temperature)
packaging dimensions 43 x 43 x 105mm
gross weight 200g
Customs tariff number 85365019
WEEE number 40951076
