Diffuse-reflections sensor for integration - Capacitive

KY98E021

KY98E021
List price
147,10 €
amount price discount
1 147,10 €
5 142,69 € 3% / 4,41 €
10 139,75 € 5% / 7,35 €
20 135,33 € 8% / 11,77 €
50 129,45 € 12% / 17,65 €
On demand
Sensor capacitive, pushbutton, 59mm, symbol "hand", 10-30V DC, -30-70°C, PNP NO, cable with connector 4pole 0.2m, IP67, plastic anodized/anodized, LED
Compare

Diffuse-reflections sensor for integration - Capacitive

Capacitive proximity switches are contact-free sensors. They detect metallic and non-metallic objects, regardless of whether they move or not. The achievable sensing range of the devices depends on the object material, its dimensions and the response sensitivity, which is set via a potentiometer. The vibration-resistant sensors can be approached laterally or frontally. Capacitive proximity switches are used for presence detection (e.g. sealing detection), positioning (e.g. PET bottles), counting (e.g. plastic caps), level detection (e.g. lubricant) or distance measurements (e.g. thickness measurement) of solid and liquid materials.

Electrical properties

Type of switching function
Normally open contact (NO)
Type of electrical connection
Cable connector
Type of switching output
PNP
Rated switching current
400mA
Short-circuit protection
Yes
No-load current
30mA
Number of pins
4
Voltage drop
3V
Reverse polarity protection
Yes
Operating voltage (DC)
10 - 30V
Display
LED display

Mechanical properties

Design
Round
Cable length
0.2m
Hole diameter
59mm
Maximum tightening torque
1Nm
Mounting method
Counter thread
Surface
teflon coated
Degree of protection (IP)
IP67
Housing material
Plastic

Other properties

Printing
Symbol "hand"
Ambient temperature
-30 - 70°C
With front ring
Yes
Classification Class
eClass-7.0 27371228
eClass-7.1 27371228
eClass-8.0 27371228
eClass-9.0 27371228
eClass-9.1 27371228
ETIM-6.0 EC001028
ETIM-7.0 EC001028
Property Value
RoHS‑compliant Yes
Reach-compliant Yes
IPF Product Group 690 diverse sensors
packaging dimensions 74 x 74 x 143mm
gross weight 100g
Customs tariff number 85365019
WEEE number 40951076
