| amount | price | discount |
|---|---|---|
| 1 | 299,20 € | – |
| 5 | 290,22 € | 3% / 8,98 € |
| 10 | 284,24 € | 5% / 14,96 € |
| 20 | 275,26 € | 8% / 23,94 € |
| 50 | 263,30 € | 12% / 35,90 € |
The article OV580925 is an amplifier with two channels that belongs to the subgroup "Amplifiers". As part of the "High-performance light barriers" super-group, it is characterized by its high performance and versatile application possibilities. The amplifier can independently distinguish between the light barriers in operation and has a range of up to 50000mm. Due to its multiplex function, it is particularly suitable for applications where light barriers are arranged close together. The simple installation, robust design and user-friendliness make the OV580925 amplifier a reliable solution for demanding industrial applications.
| Classification | Class |
|---|---|
| eClass-7.0 | 27210121 |
| eClass-7.1 | 27210121 |
| eClass-8.0 | 27210121 |
| eClass-9.0 | 27210121 |
| eClass-9.1 | 27210121 |
| ETIM-6.0 | EC001485 |
| ETIM-7.0 | EC001485 |
| Property | Value |
|---|---|
| RoHS‑compliant | Yes |
| Reach-compliant | Yes |
| TSCA-compliant | Yes |
| IPF Product Group | 101 high performance through-beam sensors and amplifiers |
| packaging dimensions | 80 x 45 x 120mm |
| gross weight | 180g |
| 0,69kg CO₂e | |
| Customs tariff number | 85365019 |
| WEEE number | 40951076 |
