The article with the number "OV584980" is a single-channel amplifier for a light barrier. It belongs to the "amplifiers" subgroup, which is specially designed to process information from receivers and regulate the power of the transmitters accordingly. This subgroup is in turn part of the superordinate group "high-power light barriers".
The high-performance light barrier systems were developed for applications where conventional light barriers reach their limits. Thanks to their extreme insensitivity to dirt and long range, they are ideal for demanding applications in industries such as the wood and paper industry, vehicle washing systems, the food industry and many more.
The OV584980 amplifier can achieve a range of up to 70000mm. Its high-quality technology ensures reliable power control in interaction with the transmitter and receiver. The simple installation and handling of the amplifiers as well as their high level of user-friendliness make them an optimal solution for a wide range of applications in the industrial sector.
| Classification | Class |
|---|---|
| eClass-7.0 | 27210121 |
| eClass-7.1 | 27210121 |
| eClass-8.0 | 27210121 |
| eClass-9.0 | 27210121 |
| eClass-9.1 | 27210121 |
| ETIM-6.0 | EC001485 |
| ETIM-7.0 | EC001485 |
| Property | Value |
|---|---|
| RoHS‑compliant | Yes |
| Reach-compliant | Yes |
| TSCA-compliant | Yes |
| IPF Product Group | 101 high performance through-beam sensors and amplifiers |
| packaging dimensions | 80 x 45 x 120mm |
| gross weight | 250g |
| 0,99kg CO₂e | |
| Customs tariff number | 85365080 |
| WEEE number | 40951076 |
