Wiring sensors and actuators is much easier with our distributor islands. The individual devices are connected to the distribution terminal via an M8 or M12 connection cable ready-made at both ends. The collected trunk cable significantly reduces installation and wiring work. The operating status display provides information about the functioning of the sensors (operating voltage, switching state). This makes troubleshooting much easier, as there is a direct overview of the mode of operation of the connected peripherals.
| Classification | Class |
|---|---|
| eClass-7.0 | 27279219 |
| eClass-7.1 | 27279219 |
| eClass-8.0 | 27279219 |
| eClass-9.0 | 27440108 |
| eClass-9.1 | 27440108 |
| ETIM-6.0 | EC002585 |
| ETIM-7.0 | EC003558 |
| Property | Value |
|---|---|
| RoHS‑compliant | Yes |
| Reach-compliant | Yes |
| OzDS-compliant | Yes |
| POP-compliant | Yes |
| TSCA-compliant | Yes |
| IPF Product Group | 855 cable sockets / connectors (distributor, accessories, diverse) |
| packaging dimensions | 124 x 28 x 149mm |
| gross weight | 220g |
| 0,56kg CO₂e | |
| Customs tariff number | 85366990 |
| WEEE number | 40951076 |
