| amount | price | discount |
|---|---|---|
| 1 | 175,10 € | – |
| 5 | 169,85 € | 3% / 5,25 € |
| 10 | 166,35 € | 5% / 8,76 € |
| 20 | 161,09 € | 8% / 14,01 € |
| 50 | 154,09 € | 12% / 21,01 € |
Linking digital signals directly at the machine can contribute to a significant reduction in costs and effort. A classic application is the linking of different signals directly in the field. In this way, long cable runs of many individual devices can be avoided, this contributes to a significant minimization of the wiring effort and reduces the need for control inputs. All input signals on the logic modules are visualized by integrated LEDs and are electrically decoupled from each other. This reliably prevents influences from one device to the other. The outputs of the modules are overload-proof and the pending signal is also indicated via an LED. Along with logical input signal links such as AND or OR, versions with signal change control are also available. The ipf logic modules are available for DIN rail mounting or as field modules. Because of this and because of the robust housing, which is characterized by a high degree of protection against the ingress of dust and water, our devices can be used in all areas of machines, plants and tools.
| Classification | Class |
|---|---|
| eClass-7.0 | 27242216 |
| eClass-7.1 | 27242216 |
| eClass-8.0 | 27242216 |
| eClass-9.0 | 27242216 |
| eClass-9.1 | 27242216 |
| ETIM-6.0 | EC001417 |
| ETIM-7.0 | EC001417 |
| Property | Value |
|---|---|
| RoHS‑compliant | Yes |
| Reach-compliant | Yes |
| OzDS-compliant | Yes |
| POP-compliant | Yes |
| TSCA-compliant | Yes |
| SCIP number | 6b5dcbaa-4d3b-4e4e-a6f4-d7da4e41bc3c |
| IPF Product Group | 800 miscellaneous |
| packaging dimensions | 150 x 40 x 220mm |
| gross weight | 114g |
| 0,74kg CO₂e | |
| Customs tariff number | 85365005 |
| WEEE number | 40951076 |
