LED lights - Signal lights

EZ250320

EZ250320
List price
423,80 €
amount price discount
1 423,80 €
5 411,09 € 3% / 12,71 €
10 402,61 € 5% / 21,19 €
20 389,90 € 8% / 33,90 €
50 372,94 € 12% / 50,86 €
Scarce
LED signal light, 279x110x40mm, multicolor LED, 13W, 18-28V DC, with signal transducer, M12-connector 8-pin, IP54, aluminum+plastic, magnetic clamp
Compare

LED lights - Signal lights

LED lights are required in nearly every industrial sector. A lighting coordinated on the respective workplace ensures a better visibility, increases the production quality, the working safety and helps additionally to safe energy costs. Their long lifetime, which is independent of switching cycles, reduces maintenance costs and increases the availability. LED lights are used for the illumination of workplaces, work areas of machines, control cabinets and several other fields of application.

Electrical properties

Type of electrical connection
Connector M12
Rated operating current
520mA
Power
13W
Number of pins
8
Protection class
III
Version of the acoustic signal generator
Buzzer (90dB)
Operating voltage
Electrical connection

Mechanical properties

Design
Cuboid
Width
40mm
Height
279mm
Length
110mm
Mounting method
Magnet holder
Degree of protection (IP)
IP54
Front screen scattering behavior
diffuse
Housing material
Aluminum
Front screen material
Polycarbonate
dimensions

Optical properties

Risk group
0
Lamp
LED
Light source
Multi-colored LED
Signal color
Blue, Yellow, Green, Magenta, orange, Red, White

Other properties

Ambient temperature
-20 - 40°C
Number of segments
5
Classification Class
eClass-7.0 27110390
eClass-7.1 27110390
eClass-8.0 27110390
eClass-9.0 27110345
eClass-9.1 27110345
ETIM-6.0 EC000348
ETIM-7.0 EC000348
Property Value
RoHS‑compliant Yes
Reach-compliant Yes
TSCA-compliant Yes
IPF Product Group 190 machine illuminations
packaging dimensions 127 x 68 x 320mm
gross weight 828g
0,46kg CO₂e
Customs tariff number 94054239
WEEE number 40951076
