Process Data Analysis - Accessories
AB000009
On demand
Accessories IoT gateway, module, 25x139x110mm, 12x digital inputs, 6x digital outputs, 4x analog inputs, 2x analog outputs, terminal, IP20
Compare
Process Data Analysis - Accessories
12x DIN (digital input), 6x DO (digital output), 4x AIN (analog input) and 2x AO (analog output)
Electrical properties
- Number of digital outputs
- 6
- Number of digital inputs
- 12
- Power consumption
- 24VA
- Display
- LED display
- Number of analog output channels
- 2
- Number of analog input channels
- 4
- Operating voltage
- 22-26VDC
Mechanical properties
- Height
- 139mm
- Length
- 109mm
- Storage temperature
- -40 - 85°C
- Mounting method
- Top hat rail
- Degree of protection (IP)
- IP20
- Housing material
- Nylon 6 with 30% glass fibers
- dimensions
- 139mm high
Other properties
- Relative air humidity (non-condensing)
- 20 - 90%
- Ambient temperature
- 0 - 50°C
Datasheets
Manuals
Firmware
Firmware older versions
Product Compliance
-
pdfUKCA declaration of conformityPDF-file, 479 KB
-
pdfMaterial compliancePDF-file, 477 KB
-
pdfEU declaration of conformityPDF-file, 407 KB
-
pdfUL declaration of conformityPDF-file, 254 KB
-
pdfCCC declaration of conformityPDF-file, 248 KB
-
pdfCSA declaration of conformityPDF-file, 243 KB
Product flyers
Whitepapers
-
pdfEnergy monitoring and production / process data acquisitionPDF-file, 918 KB
-
pdfEnergy monitoring and condition monitoringPDF-file, 661 KB
Application examples
| Classification | Class |
|---|---|
| eClass-7.0 | 27143190 |
| eClass-7.1 | 27143190 |
| eClass-8.0 | 27143190 |
| eClass-9.0 | 27143154 |
| eClass-9.1 | 27143154 |
| ETIM-6.0 | EC001099 |
| ETIM-7.0 | EC001099 |
| Property | Value |
|---|---|
| RoHS‑compliant | Yes |
| Reach-compliant | Yes |
| TSCA-compliant | Yes |
| IPF Product Group | 735 Gateway and accessories |
| packaging dimensions | 220 x 40 x 165mm |
| gross weight | 190g |
| 1,69kg CO₂e | |
| Customs tariff number | 85437090 |
| WEEE number | 40951076 |
