| amount | price | discount |
|---|---|---|
| 1 | 71,90 € | – |
| 5 | 69,74 € | 3% / 2,16 € |
| 10 | 68,31 € | 5% / 3,60 € |
| 20 | 66,15 € | 8% / 5,75 € |
| 50 | 63,27 € | 12% / 8,63 € |
Our multi-function time relays / pulse stretchers can be considered as real alternatives when it comes to solutions for minor set control technology problems. The input signals, for example, can be switch-on or off delayed after a preset time. In order to be able to reduce the storage, multi-function relays can be used that provide, in addition to the already mentioned functions, operating modes like time-programming, pulse-forming or clocking. Besides, there is also star / delta change-over for load-contactors integrated in the motor start control. Reversing the switching logic or the polarity is possible with our fast signal inverters / impulse stretchers. These are characterized by extremely short response times and high switching frequencies. As an input circuit for a PLC these devices are perfect to record short signal or level changes.
| Classification | Class |
|---|---|
| eClass-7.0 | 27371790 |
| eClass-7.1 | 27371790 |
| eClass-8.0 | 27371605 |
| eClass-9.0 | 27371605 |
| eClass-9.1 | 27371605 |
| ETIM-6.0 | EC001439 |
| ETIM-7.0 | EC001439 |
| Property | Value |
|---|---|
| RoHS‑compliant | Yes |
| Reach-compliant | Yes |
| TSCA-compliant | Yes |
| IPF Product Group | 800 miscellaneous |
| packaging dimensions | 77 x 25 x 123mm |
| gross weight | 26g |
| 0,26kg CO₂e | |
| Customs tariff number | 85365005 |
| WEEE number | 40951076 |
