NEW IN THE PROGRAM

SL920027

SL920027
List price
1.389,00 €
On demand
Sensor flow, air, calorimetric, 183x75x475mm, R 1", 18-36V DC, 4-20mA, M12 plug connector 5-pin, plastic PC, pressure resistance 16bar, with display, parameterization, Ethernet PoE (Power over Ethernet)
circuit diagram
dimensional drawing
3D model
Compare

Flow sensors - Consumption measurement for compressed air

The function of the flow sensor is based on the calorimetric principle. The sensor is heated by a few degrees Celsius from the inside compared to the flow medium into which it protrudes. If the medium flows, the heat generated in the sensor is dissipated by the medium. The temperature generated in the sensor is measured and compared with the temperature of the medium, which is also measured. The flow state for each medium can be derived from the temperature difference obtained. Applications for these sensors include compressed air consumption measuring devices.

Electrical properties

Type of analog output
4 - 20mA
Type of electrical connection
Connector M12
Type of interface connection
Plug-in connection M12
Setting procedure
Parameterization
Coding of interface connection
X
No-load current
120mA
Measurement principle
calorimetric
Number of pins of interface connection
8
Supported communication interface
Modbus RTU
Measuring range flow volume
0 - 4,833.33l/min
Measuring range flow velocity
0.18 - 185m/s
Display
TFT display
Short circuit protection, Reverse polarity protection
5
A
Operating voltage
18-36VDC
Electrical connection
M12 plug connector

Mechanical properties

Type of process connection
R1 inch
Design
Cuboid, integrated measuring section
Width
475mm
Pressure resistance
16bar
Height
179.2mm
Length
75mm
Medium temperature
-30 - 80°C
Degree of protection (IP)
IP65
Housing material
Plastic PC
Sensing element material
Stainless steel 1.4301
dimensions
75x475x179,2mm

Other properties

Relative air humidity (non-condensing)
95%
Ambient temperature
-20 - 70°C
Measuring accuracy
± 1.5 % of measuring range ± 0.3 % of measuring range end
Reference medium / object
Air
Pneumatic applications
