Catalog data sheet
PDF-file, 1.1 MB
amount | price | discount |
---|---|---|
1 | 316,50 € | – |
5 | 307,01 € | 3% / 9,50 € |
10 | 300,68 € | 5% / 15,83 € |
20 | 291,18 € | 8% / 25,32 € |
50 | 278,52 € | 12% / 37,98 € |
The monitoring of rotation speed or rotating movements is necessary in many applications to ensure the proper operation of the plant. Our rotation- and zero speed monitors operate according to different operating principles: 1. Monitoring of pulses of a transducer via a current transfomer, 2.Frequency measurement of the phase current Our devices feature, depending on the type, a wide variety of functions. For a further evaluation in a higher-level control, the results are i.e. outputted as easy relay contact (over-/ underspeed) or as analog output signal resolved to the set rotation speed range.
Classification | Class |
---|---|
eClass-7.0 | 27200316 |
eClass-7.1 | 27200316 |
eClass-8.0 | 27200316 |
eClass-9.0 | 27200316 |
eClass-9.1 | 27200316 |
ETIM-6.0 | EC002300 |
ETIM-7.0 | EC002300 |
Property | Value |
---|---|
RoHS‑compliant | Yes |
Reach-compliant | Yes |
IPF Product Group | 650 monitors |
packaging dimensions | 185 x 107 x 195mm |
gross weight | 452g |
Customs tariff number | 90292038 |
WEEE number | 40951076 |
